The devices support the following standard telegrams:
Standard
telegram
M
⇒ S
Standard
telegram
S
⇒ M
Configuration data
- 1 0x42,0x82,0x05,0x03
- 2 0x42,0x84,0x05,0x08
2 7 0xC4,0x87,0x8A,0x0A,0x0A,0x05,0x03
2 8 0xC4,0x87,0x8C,0x0A,0x0A,0x05,0x08
- 201 0x44,0x85,0x05,0x03,0x05,0x0A
- 202 0x44,0x87,0x05,0x08,0x05,0x0A
2 203 0xC6,0x87,0x8D,0x0A,0x0A,0x05,0x03,0x05,0x0A
2 204 0xC6,0x87,0x8D,0x0A,0x0A,0x05,0x03,0x05,0x0A
5 I&M Identification & Maintenance Functions
I&M is a concept for manufacturer- and sector-independent standardized identi-
fication of field devices. The field device provides specific information in an elec-
tronic nameplate, which can be primarily accessed online with initial operation and
maintenance.
The reading and writing is made on an I&M parameter block consisting of
64 octets.
Content Octets Coding (H)
Header
Manufacturer specific 10 00
H
I&M Block
MANUFACTURER_ID 2 017A
H
= INFICON
ORDER_ID 20 Ordering no.
SERIAL_NUMBER 16 Serial no.
HARDWARE_REVISION 2 Hardware revision
SOFTWARE_REVISION 4 Firmware revision
REVISION_COUNTER 2 Revision counter
PROFILE_ID 2 5A00
H
PROFILE_SPECIFIC_TYPE 2 0000
H
IM_VERSION 2 0101
H
IM_SUPPORTED 2 0000
H
4.4.2 Configuration Data
5.1 I&M0
