7 Device Block
The following table lists the services and parameters integrated in the Device Block
(
→ Appendix A for abbreviations).
ID Name Structure Data type Bytes Access Store See section
15 Device Block State Simple UINT8 1 1_R/W
2_R/W N 7.2.2
16 Block Type ID Simple OSTRING(n) 4 1_R
2_R N 7.1.1
17 Device Type Simple VSTRING(n) 8 2_R N 7.1.2
18 Standard Revision Level Simple VSTRING(n) 9 2_R N 7.1.3
19 Device Manufacturer
Identifier
Simple VSTRING(n) 20 2_R N 7.1.4
20 Manufacturer
Model Number
Simple VSTRING(n) 20 2_R N 7.1.5
21 Software or Firmware
Revision Level (Profibus
Adapter)
Simple VSTRING(n) 8 2_R N 7.1.6
22 Hardware Revision Level
(Profibus Adapter)
Simple VSTRING(n) 8 2_R N 7.1.7
23 Serial Number Simple VSTRING(n) 30 2_R N 7.1.8
24 Device Configuration Simple VSTRING(n) 50 2_R N 7.1.9
25 Device State Simple UINT8 1 0_XI
1_R
2_R
V 7.1.10
26 Exception Status Simple UINT8 1 0_XI
1_R
2_R
V 7.1.11
27 Exception Detail Alarm Record → below - 1_R
2_R
V 7.1.12
28 Exception Detail
Warning
Record → below - 1_R
2_R
V 7.1.13
36 Run hours Simple UINT16 2 1_R
2_R
V 7.1.14
202 Basic Device Firmware
Revision Level
Simple VSTRING(n) 8 2_R N 7.1.15
203 Basic Device Hardware
Revision Level
Simple VSTRING(n) 8 2_R N 7.1.16
204 Common Exception
Detail Alarm
Array UINT8 2 1_R
2_R
V 7.1.17
205 Device Exception Detail
Alarm
Array UINT8 2 1_R
2_R
V 7.1.18
206 Manufacturer Exception
Detail Alarm
Simple UNIT8 1 1_R
2_R
V 7.1.19
207 Common Exception
Detail Warning
Array UINT8 2 1_R
2 _R
V 7.1.20
208 Device Exception Detail
Warning
Array UINT8 3 1_R
2_R
V 7.1.21
209 Manufacturer Exception
Detail Warning
Simple UINT8 1 1_R
2_R
V 7.1.22
210 Address Switch Simple UINT8 1 1_R
2_R V 7.1.23
