If one of bits 4…6 is set in the Exception Status, the current warning can be read in
the parameter "Exception Detail Warning". The Exception Detail Warning pa-
rameter consists of a total of 9 bytes that inform on the error status of the gauge.
Due to the use of the extended error output format, these bytes have the following
structure:
Byte
no
Name Description Value
Common Exception Detail Warning
0 Size Number of subsequent bytes
used for description of the
warning 2
1 Detail 0 Error message
(simple, UINT8, 1 byte) See table above
2 Detail 1 Error message
(simple, UINT8, 1 byte) See table above
Device Exception Detail Warning
3 Size Number of subsequent bytes
used for description of the
warning 3
4 Status extension Status extension
(simple, UINT8, 1 byte)
Status extension
(ID 102) of CDG
Transducer Block
5
6 Detail Error message
(array, UINT8, 2 bytes)
Sensor Warning
(ID 104) of CDG
Transducer Block
Manufacturer Exception Detail Warning
7 Size Number of subsequent bytes
used for description of the
warning 1
8 Detail Error message
(simple, UINT8, 1 byte) See table above
This parameter identifies the number of hours that the basic device has been
powered ON. The parameter has a resolution of 1 hour.
This proprietary parameter describes the firmware version of the basic device.
This proprietary parameter describes the version of the basic device hardware.
This proprietary parameter allows access of the corresponding part (Detail 0 and
Detail 1) of the Common Exception Detail Alarm parameter (ID 27). See section
7.1.12.
This proprietary parameter allows access of the corresponding part (Detail) of the
Device Exception Detail Alarm parameter (ID 27). See section 7.1.12.
This proprietary parameter allows access of the corresponding part (Detail) of the
Manufacturer Exception Detail Alarm parameter (ID 27). See section 7.1.12.
This proprietary parameter allows access of the corresponding part (Detail 0 and
Detail 1) of the Common Exception Detail Warning parameter (ID 28). See section
7.1.13.
7.1.13 Exception Detail
Warning (ID 28)
7.1.14 Run hours (ID 36)
7.1.15 Basic Device Firmware
Revision Level (ID 202)
7.1.16 Basic Device Hardware
Revision Level (ID 203)
7.1.17 Common Exception
Detail Alarm (ID 204)
7.1.18 Device Exception Detail
Alarm (ID 205)
7.1.19 Manufacturer Exception
Detail Alarm (ID 206)
7.1.20 Common Exception
Detail Warning (ID 207)
