Description

3 - GAUGES, EXT

Connection for optional external pressure measurement locations (0 ... 10 V or
0 … 20 mA) for INFICON Service

Connection plug arrangement

4 - 1

Connection for PIRANI gauge, test leak and suppressor on the pre-amplifier (pre-
mounted, three-core cable)

5 - 24VDC

Connection for 24 V power supply pack used to supply mass spectrometer module,
control unit, I/O module and bus module.

6 - 2

Connection for inverter turbo molecular pump and fan turbo molecular pump (pre-
mounted, two-core cable)

7 - ION SOURCE

Connection for ion source

8 - 3

Connection for pre-amplifier

9 -

Power LED

The Power LED and Status LED indicate the status of the unit; see no. 12 - S

TATUS

.

10 - SERVICE

RS232 connection for INFICON Service

11 - I/O / ANYBUS

Connection for I/O or bus module or control unit

Information The connections I/O / A

NYBUS

and C

ONTROL

U

NIT

have the same

functions. You have the choice of connecting:

– Control unit CU1000 + I/O module IO1000 or
– Control unit CU1000 + bus module BM1000 or
– I/O module IO1000 + bus module BM1000 or
– 2 control units CU1000 or
– 2 I/O modules IO1000 (configurable only together)

1

+24 V output, max. 200 mA

2

Input for P3 service gauge, 0 ... 10 V

3

GND

4

Reference to input for P3 service gauge

5

20 mA input for P3 service gauge
