Starting the Controller

Protocol Manager Instruction Manual

38

Version 1


Copyright © 2013 by Despatch Industries.

All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.

4.

Starting the Controller

4.1. Working with Recipes and Profiles


4.1.1. Create a New Profile

For help creating recipes consult Section 3.7.

4.1.2. Open an Existing Saved Recipe

1. Press

OPEN

on the Recipe Editor screen.

2. Select the recipe from the list of saved recipes and press

OPEN

to populate the recipe.

3. Write the recipe to the controller (Refer to Section Error! Reference source not found.).



4.2. Start a Controller

Prepare to start by reading the recipe from the
controller (See Sections 3.7.1.5 or 3.7.2.5) or
writing the desired recipe to the controller (See
Sections 3.7.1.3or 3.7.2.3).

Start a Protocol 3 or Protocol Plus controller by
pulling down

Window

(

Figure 27

) and selecting

Network Summary

(

Figure 28

).


“Profile” and “Recipe” are used interchangeably throughout
the Protocol 3, Protocol Plus, Protocol Manager to indicate
those instructions assigned to carry out certain processes.

Figure 27. Window Pull-Down Menu.
