Protocol Manager Instruction Manual I NSTALLATION & S ETUP
Version 1 35
Copyright © 2013 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
Table 6. Profile Datalog Tab.
Field
Description Parameters
Log File Header Information
Controller Name
Controller Name
Check box to select the desired header data to
include in the log file
Start Date and Time Start Date and Time
Operator ID Unique operator ID
Lot Information Lot information
supplied by operator
Tracking Data
Log File Record Data
Elapsed Time
Time since
beginning of process
run
Check box to select the desired types of data to
include in the log file
Entry Date and Time Entry Date and Time
Temperature Setpoint Temperature
Setpoint
Temperature Value Temperature Value
Alarms and Events Alarms and Events
PID Control Value PID Control Value
Log File Folder
Log at Intervals/
Log at Profile Change
For Log at Intervals:
Choose desired time
to log data
Select whether logging will occur at set time
intervals or at every change point programmed
into the recipe, for instance, Start point,
beginning of ramp, and the like. Typically a short
run with few steps might use the time intervals
option while a long run with many steps might
use the profile change option.
Log Entry Interval Slide to select
desired longer inter
intervals In seconds or minutes
Log File Folder Click Browse to
navigate to desired
folder.
Log File Naming Options
Controller ID
Choose address or
name as controller
ID Controller ID identifies the controller by address
(three digits with leading zeroes) or name. If
name is selected, blank spaces and characters
not legal for use in a Windows file name are
converted to underscore characters.
Time Stamp Choose desired
format for the time
stamp
Log File Naming Options
The Controller ID and Time Stamp are combined, but separated by an underscore character, to
create a datalog file name prefix. The file name is automatically appended with a ".log"
extension.
