Table 4. Protocol 3 Controller Recipe Editor Fields and Descriptions.
Field
Description
Parameters
Recipe
Name
Name of new recipe
being created
Defaults to “NEW.” Replace with desired name.
Seg #
Shows the number
of the profile
segment being
created
From 1-255
Type
Set the segment
type.
Ramp Time: time to reach target SP
Ramp Rate: rate of change towards target SP
Step: jump to target SP
Dwell: keep current SP
Hold: hold the profile until released
Loop: back to previous segment
Join: join to another profile)
End :end the profile
Repeat Sequence Then End: repeat a sequence of joined
profiles
—of which this is the last
A Join, End or Repeat
Sequence Then End will become the last segment in the profile
Time
Desired Time
HH:MM:SS
Seg/Pr #
Seg: Segment
number used with
the Loop command
Pr#: Profile number
used with the Join
command
Use “Seg” to identify the segment to return to when using the Loop
command.
EV1
Events turn on for
the duration of the
segment.
For End Segments, the event state persists until another profile
starts, the user exits from profiler mode, or the unit is powered down.
EV2
EV3
EV4
EV5
Times To
Cycle
Program
Enter the number of
times to run the
complete program
From 10
Profile
Start
Trigger
Instruction to begin
the selected profile.
From: None (profile start is not delayed);
After Delay or Day and Time
Profile
Recovery
Method
The power-on action
if profile was running
at power-down (for
example, after a
power cut), or
following correction
of a signal break.
From: Control outputs off; Restart profile; Maintain last profile
setpoint; Use controller setpoint; Continue profile from where it was
when power failed.
Profile
Abort
Action
Action after profile is
forced to stop before
its end.
From: Control outputs off; Maintain last profile setpoint or Use
controller setpoint.
OPEN
Opens a recipe
saved to the host
PC
