I NSTALLATION & S ETUP Protocol Manager Instruction Manual
22 Version 1
Copyright © 2013 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
Protocol Plus Controller Only:
When the controller is running in Timer or Profile mode, click
Run / Hold to put the
process in Hold. Disable this function so it remains a Run only button by checking the
box next to
DISABLE Process HOLD Function .
3.4.5. Passwords Tab Setup
Use the Passwords tab to select software login levels for the Protocol Manager Software. Protocol
Manager provides four levels of access for operators using the ovens (Table 3).
Table 3. Protocol Manager Levels of Access.
Access Level /
Password
Access Allowed
Level 4
Highest level of access. Level 4 operators can change communication
settings, add/delete controllers from the network, change passwords and
perform all lower-level operations.
Level 3
Level 3 operators can edit/write recipes, configure data log settings and
perform all lower-level operations.
Level 2
Level 2 operators can change controller modes, select profiles, change set
points, start data logging and perform Level 1 operations.
Level 1
Lowest level of access. Level 1 operators view run-time status, and start, stop
or hold controller operation. No password is required.
Figure 17. Windows Tab.
