Dakota Ultrasonics
35
3) When the desired units are displayed, immediately press and release the
button to set the units in the UMX-2. For this example, IN has been
selected.
4) Press and hold the button to escape out of the sub menu options at any
time.
8.4 Display Backlights & LEDs
Depending on the required visibility versus power consumption, the UMX-2 provides
three lighting options; On, Off, AUTO. The following describes each option:
LT ON: Toggles both the display backlights and LED’s on.
LT OFF: Toggles all the lights off.
LAUTO: Toggles both the display backlights and LED’s on, only when receiving an
echo (measurement).
The following procedure explains how to set the lighting option in the UMX-2:
Setting Light Option
1) Press and hold the single UMX-2 button, located on the top end cap, until
the top level menu options begin scrolling on the alpha display. Once this
occurs, the button can now be released. The menu options will scroll one to
the next in a time delayed sequence, and will display all the menu options in
a continuous loop.
