Dakota Ultrasonics
9
Press & Release:
Primary function – selection of menu items.
To select a menu item, press and release the button. The sub menu items will begin
scrolling on the display. Finally, to select a sub menu item, press and release again.
Press & Long Hold:
Primary function – manually turn off the UMX-2.
The UMX-2 will automatically shut off after 5 minutes if it hasn’t detected a
measurement. However, to be sure the unit is shut off after use, when the button is
pressed and held down for approximately 10 seconds, “POWER” “OFF” will be
displayed, and the unit will manually turn off. Once the unit turns off, the button can
be released.
It’s really just that simple!
3.3 Gauge Settings
The current settings of the UMX-2 will be displayed on initial power up and every 30
seconds following. This is intended to provide the user with an easy way to confirm
the settings at any time, witho ut having to scroll to the specific menus items
individually. The parameters will be displayed in the order that follows:
Gauge Model: UMX-2
Battery Status: LO, MED, or HI
Transducer Type Identified: ½ 5, ½ 3.5, ½ 2 S, ½ 5 S
Measurement Mode: P-E, PECT, E-E or TCG
Current Gain Setting: VLOW, LOW, MED, HIGH, VHIGH
Material Type: ALU, STL, STST, IRON, CIRO, PVC, PLST, PLUR, or Custom
However, if the user is in the menus and viewing the sub menu items, the currently
selected option/feature can be identified by the “,” (comma) illuminated in the top left
corner of the small display.
3.4 Menu Structure
The UMX-2 has been carefully designed to minimize the overall level of drop down
menu options in an effort to keep the gauge as simple to operate as possible. The
diagram below illustrates the entire menu structure of the UMX-2:
