109
0x1600 (5632) 40 words R
Count of Bad Packets of RX
Ex. Port 1 gets 0x2EEEE1FFFF bad packets of
RX.
Word 0 of Port 1 = 0x0000
Word 1 of Port 1 = 0x002E
Word 2 of Port 1 = 0xEEE1
Word 3 of Port 1 = 0xFFFF
Word 0,1,2,3 = Port 1 good packets
Word 4,5,6,7 = Port 2 good packets
Word 8,9,10,11 = Port 3 good packets
Word 12,13,14,15 = Port 4 good packets
Word 16,17,18,19 = Port 5 good packets
Word 20,21,22,23 = Port 6 good packets
Word 24,25,26,27 = Port 7 good packets
Word 28,29,30,31 = Port 8 good packets
Word 32,33,34,35 = Port 9 good packets
Word 36,37,38,39 = Port 10 good packets
Redundancy Information
0x2000 (8192) 1 word R
Redundancy Protocol
0x0000: None
0x0001: STP
0x0002: RSTP
0x0004: ERPS
0x0008: iA-Ring
0x0010: Compatible-Ring
0x2100 (8448) 1 word R
STP Root
0x0000: Not Root
0x0001: Root
0xFFFF: RSTP not enable
0x2101 (8449) 5 words R
STP Port Status
0x00: Disabled
0x01: Listening
0x02: Learning
0x03: Forwarding
0x04: Blocking
0x05: Discarding
0xFF: RSTP Not Enable
Word 0 Hi byte = Port 1 Status
Word 0 Lo byte = Port 2 Status
Word 1 Hi byte = Port 3 Status
Word 1 Lo byte = Port 4 Status
Word 2 Hi byte = Port 5 Status
Word 2 Lo byte = Port 6 Status
Word 3 Hi byte = Port 7 Status
Word 3 Lo byte = Port 8 Status
Word 4 Hi byte = Port 9 Status
Word 4 Lo byte = Port 10 Status
