C-7 Printer-Applicator-System PAM 3000
Pressing the key will stop the print job and the printer will be reset.
EXF is active when current flows between PIN9 and PIN21.
EUEB - Label is taken - variation without applicator
The label is taken from the dispense position. EUEB is active when current flows between
PIN10 and PIN22.
EUEB - Recycle part in position - variation with applicator
The recycle part is in the position to take-over the labels. EUEB is active when current flows
between PIN10 and PIN22.
STRT - Start signal - both variations
The STRT signal triggers the start of the print with an impulse of 20 ms.
XSTART is active when current flows between PIN11 and PIN23.
DRW - Print repeat - variation without applicator
The print of the last label should be repeated. DRW is active when current flows between
PIN12 and PIN24.
DRW - GoodRead (Scan result) - variation with applicator
The signal indicates the good result of scanning.
DRW is active when current flows between PIN12 and PIN24.
ESP - Label dispense - variation without applicator
The label should be dispensed. ESP is active when current flows between PIN13 and PIN25.
ESP - 90°-labelling - variation with applicator
The label should be applied in the 90°-position. ESP is active when current flows between
PIN13 and PIN25.
XTIV - Position of the peel-off table - both variations
The signal is necessary to recognize whether the peel-off table is in its front or back position.
XTIV is active if the peel-off table is in its back position.
In this state the contact between PIN15 and RÜL (PIN7) is opened.
XVW - Warning end of material - both variations
This signal reports that there is only still a few amount of material (ribbon or label media)
available. The user has to check the warning sensors ribbon end and label end.
In this state the contact between PIN16 and RÜL (PIN7) is opened.
XEDST - Print of label has started - variation without applicator
It is indicated that the print of a label has started.
XEDST is active if the contact between PIN17 and RÜL (PIN7) is closed.
XEDST - Pad in starting position - variation with applicator
The pad has reached the starting position.
XEDST is active if the contact between PIN17 and RÜL (PIN7) is closed.
XRTA - Activate the recycle part - variation with applicator
The recycle part for the bad labels should be activated.
XRTA is active if the contact between PIN18 and RÜL (PIN7) is closed.
