The ALARM button can be used, for example, to call dispatch. The announcer
calls the numbers configured in the memory of the button ALARM – set 2
(021-026).The lighting of the button ALARM (not required by a standard) makes
it possible to find the announcer easily in the dark.
After pressing the Alarm or triphony button the function is called up immediately.
We can speak handsfree or connect an earpiece for better acoustic properties.

The voice menu is called up pressing

for longer than 2s.

Before you start

Requirements:

If you connect an earpiece to the announcer. Use the earpiece supplied by the
manufacturer. A different earpiece need not work.

Checking completeness of product

Before starting installation check to see whether the packaging of the product is
complete:

1 announcer including these elements
1 earpiece
2 wall plugs
2 screws for wall plugs
7-8 jumpers for configuration of common machine room

Mounting

The announcer is usually mounted on a wall using the appended wall plugs and screws.

Electrical Installation

Description of connectors

On the right side under the cover there are 3 connectors
