2N Lift8 v1.0 User Manual

Page 134

134

Plans Menu

Figure:

Click Add plan to create a new plan. When the file browser opens, select a file from the
local disk to be added. Find the preview of the image to be imported to the right. Click
Save to confirm addition.

Click on the plan to display the view. Click Display lifts next to the Plan name to view
the lift positions if any. All the configured lifts will get displayed in the form of a lift
symbol plus phone number; refer to the figure above. Select a plan and press Remove
plan to remove the plan. Use the Change plan button to update the building plan while
keeping the current lift configuration and plan name. Click Download plan to back up
the building plan on a local disk without the lift position symbols.

Tip

All the saved plans are stored in the

and thus

2N Lift8 Server

accessible to all the authorised users.

Note

Add the images in the PNG, JPG or BMP format.
The filebrowser is set to PNG by default. If you cannot view your images
in the selected folder, change the file format (typically in the right-hand
bottom corner next to the file name).
