SECTION 7 - BASIC ELECTRICAL INFORMATION & SCHEMATICS
3121262 – JLG Lift – 7-17
WHITE
RED
13 14
22 21
BLA
C
K
WHIT
E
BLACK
RE
D
TRANSPORT LIMIT
SWITCH WIRING.
SECTION A-A
THIS EXAMPLE OF A SEALED CONNECTOR SHOWN FOR
CLARITY. PROCESS APPLIES TO ALL SEALED CONNECTORS.
TAIL LIGHT
TAIL LIGHT
ALARM
PLATFORM
CONTROL BOX
PLATFORM LEVEL
SENSOR #1
(RIGHT-PRIMARY)
PLATFORM LEVEL
SENSOR #2
(LEFT-SECONDARY)
AUX PUMP
APPLY IN ALL UNSEALED CONNECTORS PER MPS FI-001 AND FI-042.
APPLY TO FEMALE TERMINALS IN SEAED CONNECTORS AS SHOWN IN VIEW BELOW
WITH THE FOLLOWING EXCEPTIONS:
***DO NOT APPLY ON DEUTZ ENGINE EMR 2 MODULE CONNECTORS***
***DO NOT APPLY ON LSS WITH CIRCULAR CONNECTORS***
NOTE: DO NOT ATTACH ANY WIRING HARNESSES
TO FUEL SUPPLY, RETURN OR VENT HOSES.
DIELECTRIC GREASE,
APPROXIMATELY 1/2 FULL
(A THIN LAYER OF GREASE
MAY REMAIN ON CONNECTOR
FACE AND ADJACENT AREAS)
V27-PLATFORM DUMP
V29-PLATFORM LEVEL DOWN
V31-PLATFORM ROTATE RIGHT
V28-PLATFORM LEVEL UP
V30-PLATFORM ROTATE LEFT
V32-JIB LOCK PIN (IN)
V33-JIB LOCK PIN (OUT)
ATTACH MS214- TO THIS POINT
WITH THE BATTERY B- CABLE
1001119385-C
Figure 7-24. Turntable Electrical Components - Sheet 2 of 2
