SECTION 6 - JLG CONTROL SYSTEM
3121262 – JLG Lift – 6-115
33123 33 123 MAIN TELESCOPE OUT VALVE - SHORT TO BATTERY There is a Short to Battery
to the Main Telescope Out
Valve.
33130 33 130 THROTTLE ACTUATOR - SHORT TO GROUND There is a Short to Ground
to the Throttle Actuator.
33131 33 131 THROTTLE ACTUATOR - OPEN CIRCUIT There is an Open Circuit to
the Throttle Actuator.
33132 33 132 THROTTLE ACTUATOR - SHORT TO BATTERY There is a Short to Battery
to the Throttle Actuator.
33133 33 133 PLATFORM CONTROL VALVE - SHORT TO GROUND There is a Short to Ground
to the Platform Control
Valve. - Electronic leveling system
equipped vehicles only.
33134 33 134 PLATFORM CONTROL VALVE - OPEN CIRCUIT There is an Open Circuit to
the Platform Control Valve. - Electronic leveling system
equipped vehicles only.
33135 33 135 PLATFORM CONTROL VALVE - SHORT TO BATTERY There is a Short to Battery
to the Platform Control
Valve. - Electronic leveling system
equipped vehicles only.
33150 33 150 LIFT PILOT VALVE - SHORT TO GROUND There is a Short to Ground
to the Lift Pilot Valve. - Gravity Lift Down equipped
vehicles only.
33151 33 151 LIFT PILOT VALVE - OPEN CIRCUIT There is an Open Circuit to
the Lift Pilot Valve. - Gravity Lift Down equipped
vehicles only.
33152 33 152 LIFT PILOT VALVE - SHORT TO BATTERY There is a Short to Battery
to the Lift Pilot Valve. - Gravity Lift Down equipped
vehicles only.
33153 33 153 LIFT DOWN AUX VALVE - SHORT TO GROUND There is a Short to Ground
to the Lift Down Auxiliary
Valve. - Gravity Lift Down equipped
vehicles only.
33154 33 154 LIFT DOWN AUX VALVE - OPEN CIRCUIT There is an Open Circuit to
the Lift Down Auxiliary
Valve. - Gravity Lift Down equipped
vehicles only.
33155 33 155 LIFT DOWN AUX VALVE - SHORT TO BATTERY There is a Short to Battery
to the Lift Down Auxiliary
Valve. - Gravity Lift Down equipped
vehicles only.
33173 33 173 RESTRICTED TO TRANSPORT - AXLE LOCKOUT VALVE -
SHORT TO BATTERY OR OPEN CIRCUIT There is a Short to Battery
or an Open Circuit to the
Axle Lockout Valve.
33174 33 174 RESTRICTED TO TRANSPORT - BRAKE - SHORT TO BAT-
TERY OR OPEN CIRCUIT There is a Short to Battery
or an Open Circuit to the
Brake.
33182 33 182 LIFT VALVES - SHORT TO BATTERY
33186 33 186 MAIN TELESCOPE OUT VALVE - OPEN CIRCUIT There is an Open Circuit to
the Main Telescope Out
Valve.
33188 33 188 MAIN TELESCOPE OUT VALVE - SHORT TO GROUND There is a Short to Ground
to the Main Telescope Out
Valve.
33189 33 189 MAIN TELESCOPE IN VALVE - OPEN CIRCUIT There is an Open Circuit to
the Main Telescope In
Valve.
Table 6-8. Diagnostic Trouble Code Chart
DTC
Flash
Code
Sequence Fault Message Fault Description Check
