JLG 1500SJ Service Manual - Manual (Page 461)

SECTION 6 - JLG CONTROL SYSTEM
3121262 – JLG Lift – 6-9
ENGINE SHUTDOWN:
7 0
1
DISABLED: No engine shutdown.
ENABLED: Shutdown engine when coolant temperature is greater than 110 deg. C
or the oil pressure is less than 8 PSI.
1
TILT:
8 1
2
3
4
5
5 DEGREES: Reduces the maximum speed of all boom functions to creep when
tilted more than 5 degrees and above elevation; also reduces drive speed to
creep.
4 DEGREES: Reduces the maximum speed of all boom functions to creep when tilted
more than 4 degrees and above elevation; also reduces drive speed to creep.
3 DEGREES: Reduces the maximum speed of all boom functions to creep when tilted
more than 3 degrees and above elevation; also reduces drive speed to creep.
4 DEGREES + CUT: Reduces the maximum speed of all boom functions to creep
when tilted more than 4 degrees and above elevation; also disallows tower lift up,
tower telescope out, drive, main telescope out and main lift up.
3 DEGREES + CUT: Reduces the maximum speed of all boom functions to creep
when tilted more than 3 degrees and above elevation; also disallows tower lift up,
tower telescope out, drive, main telescope out and main lift up.
1
Note: Any of the selections above will light the tilt lamp when a tilted condition occurs and will sound the platform alarm when the machine is
also above elevation.
JIB:
9 0
1
2
NO: No Jib installed.
YES: Jib installed.
SIDESWING: Jib with Sideswing installed.
2
4WS:
10 0
1
NO: 2WS mode enabled.
YES: 4WS mode enabled.
1
DRIVE:
11 0
1
2WD drive mode enabled.
4WD drive mode enabled.
1
SOFT TOUCH:
12 0
1
NO: No soft touch system installed.
YES: Soft touch system installed.
0
Table 6-2. Machine Configuration Programming Information
Configuration Digit Number Description
Default
Number
