SECTION 6 - JLG CONTROL SYSTEM
3121262 – JLG Lift – 6-119
663 66 3 CANBUS FAILURE - LOAD SENSING SYSTEM MODULE
666 66 6 CANBUS FAILURE - ENGINE CONTROLLER Engine Control Module
CAN communication lost. - ECM equipped engine only.
6610 66 10 CANBUS FAILURE - BLAM BLAM CAN communica-
tion lost. - BLAM equipped vehicles
only.
6611 66 11 CANBUS FAILURE - CHASSIS MODULE Engine Control Module
CAN communication lost. - ECM equipped engine only.
6612 66 12 CANBUS FAILURE - CYLINDER LOAD PIN Cylinder Load Pin CAN
communication lost. - Cylinder Load Pin equipped
engine only.
6613 66 13 CANBUS FAILURE - EXCESSIVE CANBUS ERRORS There has been > 500 Bus
Off errors or >500 Bus Pas-
sive Errors.
6622 66 22 CANBUS FAILURE - TCU MODULE Machine Setup/ Telemat-
ics=YES, No device heart-
beat for 30 sec
6623 66 23 CANBUS FAILURE - GATEWAY MODULE Machine Setup/ Telemat-
ics=YES, No device heart-
beat for 30 sec
6629 66 29 CANBUS FAILURE - TELEMATICS CANBUS LOADING
TOO HIGH X -Telematics only
6639 66 39 CANBUS FAILURE - JIB CONTROL MODULE
6640 66 40 CANBUS FAILURE - JIB LIFT ANGLE SENSOR
6641 66 41 CANBUS FAILURE - PLATFORM LEVEL ANGLE SENSOR
680 68 0 <<< TELEMATICS >>>
681 68 1 REMOTE CONTRACT MANAGEMENT OVERRIDE - ALL
FUNCTIONS IN CREEP X -Telematics only
810 81 0 <<< TILT SENSOR >>>
813 81 3 CHASSIS TILT SENSOR NOT CALIBRATED The Chassis Tilt Sensor
has not been calibrated.
815 81 5 CHASSIS TILT SENSOR DISAGREEMENT X
820 82 0 <<< PLATFORM LOAD SENSE >>>
821 82 1 LSS CELL #1 ERROR
822 82 2 LSS CELL #2 ERROR822822
823 82 3 LSS CELL #3 ERROR823823
824 82 4 LSS CELL #4 ERROR824824
825 82 5 LSS HAS NOT BEEN CALIBRATED The Load Sensing System
Module has not been cali-
brated.
826 82 6 RUNNING AT CREEP - PLATFORM OVERLOADED All functions at creep, the
Load Sensing System indi-
cates the Platform is over-
loaded AND is configured
to warn only while the Plat-
form is overloaded.
Table 6-8. Diagnostic Trouble Code Chart
DTC
Flash
Code
Sequence Fault Message Fault Description Check
