SECTION 6 - JLG CONTROL SYSTEM
6-12 – JLG Lift – 3121262
Table 6-3. Machine Configuration Programming Settings
1500SJ
ANSI U
S
A
ANSI
Ex
po
rt
CSA
CE
Au
st
ral
ia
Ja
pa
n
Model Number 3 3 3 3 3 3
Envelope Height 1 1 1 1 1 1
Market 0 1 2 3 4 5
Engine 3 3 3 3 3 3
Glow Plug 0 0 0 0 0 0
1 1 1 1 1 1
2 2 2 2 2 2
Starter Lockout 0 0 0 0 0 0
1 1 1 1 1 1
Engine Shutdown 0 0 0 0 0 0
1 1 1 1 1 1
Tilt 1 1 1 1 1 1
2 2 2 2 2 2
3 3 3 3 3 3
4 4 4 4 4 4
5 5 5 5 5 5
Jib 0 0 0 0 0 0
1 1 1 1 1 1
2 2 2 2 2 2
4 Wheel Steer 0 0 0 0 0 0
1 1 1 1 1 1
Drive Type 0 0 0 0 0 0
1 1 1 1 1 1
Soft Touch 0 0 0 0 0 0
1 1 1 1 1 1
Gen Set / Welder 0 0 0 0 0 0
1 1 1 1 1 1
2 2 2 2 2 2
Gen Set Cutout 0 0 0 0 0 0
1 1 1 1 1 1
Head & Taillights 0 0 0 0 0 0
1 1 1 1 1 1
Load System 0 0 0 0 0 0
X 1 X X 1 1
X 2 X 2 2 2
X 3 X 3 3 3
X 4 X X 4 4
Function Cutout 0 0 0 0 0 0
X 1 1 1 1 1
X 2 X X 2 2
X 3 3 X 3 3
Ground Alarm 0 0 0 0 0 0
1 1 1 1 1 1
2 2 2 2 2 2
3 3 3 3 3 3
Oscillating Axle 0 0 0 0 0 0
1 1 1 1 1 1
Temperature 0 0 0 0 0 0
1 1 1 1 1 1
Leveling Mode 0 0 0 0 0 0
1 1 1 1 1 1
Clearsky 0 0 0 0 0 0
1 1 1 1 1 1
BOLD TEXT indicates the default setting. Plain text indicates another
available selection. ITALIC TEXT indicates the default when option is
factory installed. SHADED CELLS indicate hidden menu or selection.
