SECTION 6 - JLG CONTROL SYSTEM
3121262 – JLG Lift – 6-17
JIB LEVEL: ACCEL X.Xs Displays/adjusts jib level acceleration 0.1 to 5.0 sec 1.5
DECEL X.Xs Displays/adjusts jib level deceleration 0.1 to 3.0 sec 0.5
MIN UP XX% Displays/adjusts minimum jib level up
speed. Same as Creep speed 0 to 65% 60
MAX UP XXX% Displays/adjusts maximum jib level up
speed 0 to 100% 100
MIN DOWN XX% Displays/adjusts minimum jib level
down speed. Same as Creep speed 0 to 65% 60
MAX DOWN XXX% Displays/adjusts maximum jib level
down speed 0 to 100% 100
GROUND
MODE: M. LIFT UP XXX% Displays/adjusts fixed main lift up
speed 0 to 100% 60
M. lift DN XXX% Displays/adjusts main lift down speed 0 to 100% 60
SWING XXX% Displays/adjusts fixed swing speed 0 to 100% 60
PLATFORM LVL XXX% Displays/adjusts fixed basket level
speed 0 to 100% 75
PLATFORM ROT XXX% Displays/adjusts fixed basket rotate
speed 0 to 100% 75
MAIN TELE XXX% Displays/adjusts fixed main telescope
speed 0 to 100% 60
JIB (U/D) XXX% Displays/adjusts jib lift speed 0 to 100% 80
Not displayed if JIB = 0
JIB (L/R) XXX% Displays/adjusts jib swing speed 0 to 100% 80
Displayed if JIB = 2
JIB TELE XXX% Displays/adjusts jib tele speed 0 to 100% 80
JIB LEVEL XXX% Displays/adjusts jib level speed 0 to 100% 100
GEN SET/
WELDER: Engine XXXX RPM Control generator/welder RPM. Not
displayed if GEN
SET/WELDER = 0 1200-2800 1800
1001128803-C
Table 6-4. Machine Personality Settings and Function Speeds
SUBMENU
(DISPLAYED ON
ANALYZER 1ST
LINE)
PARAMETER
(DISPLAYED ON ANALYZER
2 ND LINE)
DESCRIPTION RANGE
DEFAULT
VALUES
TIME RANGE
(SEC)
