SECTION 6 - JLG CONTROL SYSTEM
6-116
– JLG Lift –
3121262
33190
33
190
MAIN TELESCOPE IN VALVE - SHORT TO GROUND
There is a Short to Ground
to the Main Telescope In
Valve.
33207
33
207
HORN - OPEN CIRCUIT
There is an Open Circuit to
the Horn.
33208
33
208
HORN - SHORT TO BATTERY
There is a Short to Battery
to the Horn.
33209
33
209
HORN - SHORT TO GROUND
There is a Short to Ground
to the Horn.
33279
33
279
GLOWPLUG - OPEN CIRCUIT
There is an Open Circuit to
the Glow Plugs.
- Glowplugs equipped vehi-
cles only.
33280
33
280
GLOWPLUG - SHORT TO BATTERY
There is a Short to Battery
to the Glow Plugs.
- Glowplugs equipped vehi-
cles only.
33281
33
281
GLOWPLUG - SHORT TO GROUND
There is a Short to Ground
to the Glow Plugs.
- Glowplugs equipped vehi-
cles only.
33285
33
285
ALTERNATOR EXCITATION LINE - SHORT TO BATTERY
33307
33
307
MAIN TELESCOPE FLOW CONTROL VALVE - SHORT TO
GROUND
There is a Short to Ground
to the Main Telescope Flow
Control Valve.
33308
33
308
MAIN TELESCOPE FLOW CONTROL VALVE - OPEN CIR-
CUIT
There is an Open Circuit to
the Main Telescope Flow
Control Valve.
33309
33
309
MAIN TELESCOPE FLOW CONTROL VALVE - SHORT TO
BATTERY
There is a Short to Battery
to the Main Telescope Flow
Control Valve.
33311
33
311
MAIN LIFT FLOW CONTROL VALVE - SHORT TO GROUND There is a Short to Ground
to the Main Lift Flow Con-
trol Valve.
33312
33
312
MAIN LIFT FLOW CONTROL VALVE - OPEN CIRCUIT
There is an Open Circuit to
the Main Lift Flow Control
Valve.
33313
33
313
MAIN LIFT FLOW CONTROL VALVE - SHORT TO BATTERY There is a Short to Battery
to the Main Lift Flow Con-
trol Valve.
33429
33
429
JIB LIFT UP OVERRIDE VALVE - SHORT TO GROUND
33430
33
430
JIB LIFT UP OVERRIDE VALVE - OPEN CIRCUIT
33431
33
431
JIB LIFT UP OVERRIDE VALVE - SHORT TO BATTERY
33432
33
432
JIB LIFT DOWN OVERRIDE VALVE - SHORT TO GROUND
33433
33
433
JIB LIFT DOWN OVERRRIDE VALVE - OPEN CIRCUIT
33434
33
434
JIB LIFT DOWN OVERRIDE VALVE - SHORT TO BATTERY
33435
33
435
JIB CONTROL VALVE - SHORT TO GROUND
33436
33
436
JIB CONTROL VALVE - OPEN CIRCUIT
33437
33
437
JIB CONTROL VALVE - SHORT TO BATTERY
340
34
0
<<< PLATFORM OUTPUT DRIVER >>>
343
34
3
PLATFORM LEVEL UP VALVE - SHORT TO GROUND
There is a Short to Ground
to the Platform Level Up
Valve.
Table 6-8. Diagnostic Trouble Code Chart
DTC
Flash
Code
Sequence
Fault Message
Fault Description
Check
