SECTION 1 - SPECIFICATIONS
1-2 – JLG Lift – 3121262
1.3 CAPACITIES
1.4 TIRES
1.5 ENGINE DATA
Deutz
Caterpillar
Table 1-3. Capacities
Hydraulic Oil Tank 55 gal. (208 L)
Fuel Tank - Standard 31 gal. (117 L)
Fuel Tank - Optional 52.8 gal. (200 L)
Drive Hub
Bonfiglioli
Reggiana Riduttori
2.1 quarts (2 liters) ± 10%
0.5 quarts (0.5 liters) ± 10%
Table 1-4. Tire Specifications
Size 445/50D710
Load Range J
Ply Rating 18
Foam Fill Polyurethane HD (55 Durometer)
Foam
Diameter 46.45 in. (117.9 cm)
Width 18 in. (45.7 cm)
Rim Size 15x28
Tire & Wheel Weight 867 lbs. (393 kg)
Max Tire Load 28600 lbs. (12973 kg)
Size 445/65-24
Type Solid
Diameter 45.3 in. (115.1 cm)
Width 17.3 in. (43.9 cm)
Rim Size 12.00-24
Tire & Wheel Weight 960 lbs. (435.4 kg)
Max Tire Load 28600 lbs. (12973 kg)
Table 1-5. Deutz TD2011L4 Specifications
Type Liquid Cooled
Number of Cylinders 4
Bore 3.7 in. (94 mm)
Stroke 4.4 in. (112 mm)
Total Displacement 190 cu. in. (3108 cm³)
Compression Ratio 17.5:1
Firing Order 1-3-4-2
Output 75hp (56 kW)
Oil Capacity
Cooling System
w/Filter
Total Capacity
5 Quarts (4.5 L)
11 Quarts (10.5 L)
16 Quarts (15 L)
Average Fuel Consumption 1.2 gph (4.1 lph)
Idle Engine RPM 1200
Mid Engine RPM 1800
High Engine RPM 2475
Table 1-6. Caterpillar 3.4T
Type Liquid Cooled, Antifreeze
Number of Cylinders 4
Bore 3.7 in. (94 mm)
Stroke 4.7 in. (120 mm)
Total Displacement 201 cu. in. (3294 cm³)
Compression Ratio 19.5:1
Firing Order 1-3-4-2
Output 73.7hp (55 kW)
Oil Capacity 10.5 Quarts (10 L)
Average Fuel Consumption 1.36 gph (5.14 lph)
Idle Engine RPM 1200
Mid Engine RPM 1800
High Engine RPM 2475
