SECTION 6 - JLG CONTROL SYSTEM
3121262 – JLG Lift – 6-109
Table 6-8. Diagnostic Trouble Code Chart
DTC
Flash
Code
Sequence Fault Message Fault Description Check
001 00 1 EVERYTHING OK The normal help message
in Platform Mode.
002 00 2 GROUND MODE OK The normal help message
in Ground Mode.
0010 00 10 RUNNING AT CUTBACK - OUT OF TRANSPORT POSITION Drive speed is limited to
"ELEVATED MAX" while
the vehicle is out of trans-
port position.
000 00 0 <<< HELP COMMENT >>>
0011 00 11 FSW OPEN
A drive / boom function
was selected with the
Footswitch open.
0012 00 12 RUNNING AT CREEP - CREEP SWITCH OPEN All functions at creep while
the Creep Switch is open.
0013 00 13 RUNNING AT CREEP - TILTED AND ABOVE ELEVATION All functions at creep while
the Platform is elevated
and the Chassis is tilted.
0014 00 14 CHASSIS TILT SENSOR OUT OF RANGE The Chassis is tilted > 19
degrees for more then 4
seconds. - Not reported during power-
up.
0016 00 16 ENVELOPE ENCROACHED - HYDRAULICS SUSPENDED There is an envelope viola-
tion.
- Envelope control system
equipped vehicle only.
0017 00 17 OVER MOMENT - HYDRAULICS SUSPENDED There is an over moment
violation. - Envelope control system
equipped vehicle only.
0018 00 18 UNDER MOMENT - HYDRAULICS SUSPENDED There is an under moment
violation. - Envelope control system
equipped vehicle only.
0021 00 21 ADS 1213 REINITIALIZED
0030 00 30 RUNNING AT CREEP - PLATFORM STOWED
0031 00 31 FUEL LEVEL LOW - ENGINE SHUTDOWN
0035 00 35 APU ACTIVE
0037 00 37 JIB UNLOCKED OUT OF TRANSPORT - HYDRAULICS
SUSPENDED
0038 00 38 SWING ENVELOPE ENCROACHED - HYDRAULICS
SUSPENDED
210 21 0 <<< POWER-UP >>>
211 21 1 POWER CYCLE The normal help message
is issued at each power
cycle.
212 21 2 KEYSWITCH FAULTY Both Platform and Ground
modes are selected simul-
taneously.
213 21 3 FSW FAULTY Both Footswitches are
closed for more then one
second.
