Gateway E-9220T - Manual (Page 8)

3 www.gateway.com
Back
Back
Serial port
Power connector
Card retention bar
Video port (on
PCI card)
Mouse port
Power supply modules
PCI slots
(shown with
EMI shields)
USB ports
Keyboard port
NIC (RJ-45)
Power supply
module latch
Power supply
module latch
Case cover thumbscrew
Cover release lever
Power supply LEDs
Power supply LEDs
Power connector
