Gateway E-9220T - Manual (Page 49)

44 www.gateway.com
Chapter 4: Installing Components
To configure the SATA RAID solution:
1
Open the BIOS Setup utility as described in the previous procedure.
2
Select Create RAID Volume from the Management menu.
3
Enter the name of the volume, or press E NTER to accept the default.
4
Use the up and down arrow keys to select a RAID level.
5
Set the RAID stripe size (unless your RAID level uses mirroring).
6
Set the capacity of the volume, then press E NTER to create the volume.
7
When you have defined the current volume, confirm your settings when prompted.
8
Repeat Step 2 through Step 7 to configure additional volumes.
9
Exit the RAID Configuration utility and reboot the server.
