Replacing the system board
Replacing the system board
To replace the system board:
1
Follow the instructions in “Preventing static electricity discharge” on page 29 .
2
Follow the instructions in “Opening the server case” on page 30 .
3
Remove the processor air duct by following the instructions in “Removing the
processor air duct” on page 33 .
4
Remove the memory modules by following the instructions in “Installing memory”
on page 45 .
5
Remove all of the expansion cards by following the instructions in “Installing PCI
expansion cards” on page 47 .
6
Remove the heat sink and processor by following the instructions in “Replacing the
processor” on page 51 .
7
Disconnect the power and data cables from the system board, noting their locations
and orientation. (You will reconnect the cables after you install the new board.)
