Gateway E-9220T - Manual (Page 46)

41 www.gateway.com
Installing drives
Installing or replacing a hard drive
Use these instructions to install or replace a hard drive.
To install a hard drive in an internal drive bay:
1
Follow the instructions in “Preventing static electricity discharge” on page 29 .
2
Follow the instructions in “Opening the server case” on page 30 .
3
If you are replacing a drive, go to Step 4 .
- OR -
If you are adding a new drive to an available drive bay, slide the green drive retainer
lever toward the front of the drive bay, then go to
Step 7 .
4
Disconnect the old drive’s cables from the front of the drive.
5
Slide the green drive retainer lever toward the front of the drive bay, then pull the
drive out of the bay.
6
Set any jumpers on the new drive. See the drive’s documentation for further
instructions.
Important
To install a hard drive in the bottom external 3.5-inch drive bay, follow
the instructions in
“To install a drive in an external drive bay:” on
page 39 .
Drive retainer
lever
