38 www.gateway.com
Chapter 4: Installing Components
Installing drives
Your server’s basic configuration includes one CD or DVD drive and one 3.5-inch diskette
drive. Your server also has an additional 5.25-inch drive bay and an additional 3.5-inch
drive bay.
Your server can have as many as four SATA (standard) or SCSI (optional) drives in three
internal drive bays and one external fixed drive bay (the bottom 3.5-inch bay).
As you prepare to install drives, remember:
■ Do not use the top 5.25-inch drive bay for drives which have electronic
components exposed on the top. Drive mounting rails at the top of the bay may
damage any exposed electronic components.
■ Before you install a drive, see the drive’s documentation for information on
configuring the drive, setting drive jumpers, and attaching cables.
5.25-inch drive bay
CD or DVD drive
3.5-inch floppy drive
3.5-inch external drive bay
