76 User Manual
TYPICAL CONNECTIONS
GPS Connection
F
OR
BARRACUDA
DIFFERENTIAL
BEACON
RECEIVER
RTCM 104 OUTPUT+
SIGNAL RETURN
FUNCTION
QUICK DISCONNECT BRACKET CABLE
DESCRIPTION WIRE COLOR
BLACK
RED
WHITE
GREEN
YELLOW
BROWN
GRAY
ORANGE
PINK
BLUE
POWER SUPPLY GND
POWER SUPPLY+
NMEA0183/C-COM
NMEA0183/C-COM
NMEA0183/180/180CDX/C-COM
NMEA0183/C-COM
NMEA0183/180/180CDX/C-COM
NMEA0183/C-COM
NMEA0183/180/180CDX/C-COM
SIGNALS RETURN
GND/COMMON
POWER +10-35Vdc
INPUT1+
INPUT1-
OUTPUT1+
INPUT2+
OUTPUT2+
INPUT3+
OUTPUT3+
SIGNAL - (common/return)
FUNCTION
SMART GPS SENSOR CABLE
WIRE COLOR
RED
BROWN
GREEN
WHITE
BLACK/YELLOW/SHIELD
POWER +10-35 Vdc
GPS NMEA0183 OUTPUT+
GPS NMEA0183 INPUT+
RTCM 104 INPUT+
GND/SIGNAL RETURN
FUNCTION
POWER
SUPPLY +
SMART GPS
SENSOR
GPS POWER
SWITCH
GPS Connections on Port 3
Autopilot Connection
Autopilot Connections on Port 2
External NMEA Connection
External NMEA Connections on Port 1
