52
User Manual
3.10 FISH FINDER
The chart plotter combined with the sonar performance of the Fish Finder is one
of the most advanced marine navigation system available. To select the Fish Finder
menu, first select one of the four page related to the Fish Finder:
[MENU] + [MENU] + "PAGE" + [ENTER] + "FISH FINDER" + [ENTER] + se-
lect the desired page + [ENTER]
BARRAMUNDI/BARRAMUNDI P
LUS
/MARLIN:
[DATA] + "FISH FINDER" + [ENTER] + select the desired page + [ENTER]
Once the Fish Finder page is selected, access the Fish Finder menu by pressing:
[MENU]
For more information see the specific User Manual.
NOTE
The Fish Finder display page is available only if the Fish Finder is connected
and powered On.
BARRAMUNDI/BARRAMUNDI P
LUS
/BARRACUDA/BARRACUDA
I
GPS/
STARFISH/STARFISH E/EXPLORER
3
/MARLIN:
3.11 RADAR
The Radar consists of a scanner unit which illuminates targets with microwave
energy and then collects the echoes from those targets. The scanner unit includes
the Radar antenna, transmitter, receiver and necessary electronics. The scanner
unit is connected to a chart plotter equipped with software capable of displaying
the Radar functions. To select the Radar menu, first select one of the four page
related to the Radar:
[MENU] + [MENU] + "PAGE" + [ENTER] + "RADAR" + [ENTER] + select the
desired page + [ENTER]
BARRAMUNDI/BARRAMUNDI P
LUS
/MARLIN:
[DATA] + "RADAR" + [ENTER] + select the desired page + [ENTER]
Once the Radar page is selected, access the Radar menu by pressing:
[MENU]
For more information see the specific User Manual.
NOTE
The Radar display page is available only if the Radar is connected and powered
On.
3.12 SYSTEM INFORMATION
To see details about the software and cartography data installed.
[MENU] + [MENU] + "About..." + [ENTER]
Opens the System Information page.
3.13 WORLD BACKGROUND CHARTS
The internal background charts can be updated to include the MAX A and B level
charts which provide improved marine data, rivers, lakes, terrestrial data (major
streets , highways , railways, etc...), Nav-Aids, depth areas, territorial water ar-
eas, etc... by reading them from a special data C-CARDs (contact your local dealer).
All units must have the Worldwide Background upload function that is activated
from the system.
Worldwide Background Update
The System Update menu is entered from the About page. To select this menu
follow the procedure:
Plug the special data C-CARD + [MENU] + [MENU] + "About..." + [ENTER] +
[MENU] + "Update Worldwide Cartography" + [ENTER]
