3.7.1 Input/Output Setup menu
WARNING
After every software upgrade the RAM is cleared and the chart plotter re starts
with the usual default settings. Please go to the Input/output menu and set
the proper input format once again.
BARRAMUNDI/BARRAMUNDI P
LUS
/EXPLORER
3
/MURENA/TIGERSHARK
P
LUS
/NAUTILUS
I
GPS P
LUS
/BARRACUDA/STARFISH E/MARLIN:
GPS Connection
Connect the GPS to the GPS Port (serial Port 3). To choose your preferred setting
follow the procedure:
[MENU] + [MENU] + "ADVANCED" + [ENTER] + "Input/Output" + [ENTER]
+ "Port 3 Input" + [ENTER] + "NMEA-4800-N81-N" + [ENTER]
GPS Setup Menu
To set your preferred configuration for the connected GPS.
Internal GPS
:
MURENA
I
GPS/MILLENNIUM 7/MILLENNIUM 7 C
OLOR
/BARRACUDA
I
GPS/STARFISH:
Ena-
bles or disables the Internal GPS.
Restart GPS
: Restarts all GPS processes. Once executed, the message "Done" is shown.
Diff. Corr. Source
: Sets what kind of Differential Correction will be used by the GPS between WAAS and RTCM
(beacon correction).
Navigation Speed
: Sets the Navigation Speed among Low Speed, Medium Speed and High Speed.
Autopilot Connection
Connect the Autopilot to the serial Port 1, 2 or 3.
[MENU] + [MENU] + "ADVANCED" + [ENTER] + "Input/Output" + [ENTER]
+ "Port 1/2/3 Output" + [ENTER]. Then choose your preferred setting among
the NMEA available settings NMEA 0183 4800-N81-N, NMEA 0180, NMEA
0180/CDX) and press [ENTER] to confirm.
BARRAMUNDI/BARRAMUNDI P
LUS
/EXPLORER
3
/MARLIN:
Connect the Autopilot to the serial Port 1, 2, 3, 4 or 5.
[MENU] + [MENU] + "ADVANCED" + [ENTER] + "Input/Output" + [ENTER]
+ "Port 1/2/3/4/5 Output" + [ENTER]. Then choose your preferred setting
among the NMEA available settings NMEA 0183 4800-N81-N, NMEA 0180,
NMEA 0180/CDX) and press [ENTER] to confirm.
External NMEA Connection
Connect the External NMEA to the serial Port 1, 2 or 3.
[MENU] + [MENU] + "ADVANCED" + [ENTER] + "Input/Output" + [ENTER]
+ "Port 1/2/3 Input" + [ENTER]. Then choose your preferred setting among
the NMEA available settings NMEA 1200-N81-N, NMEA 4800-N81-N, NMEA
4800-N82-N, NMEA 9600-N81-N, NMEA 38400-N81-N and press [ENTER]
to confirm.
BARRAMUNDI/BARRAMUNDI P
LUS
/EXPLORER
3
/MARLIN:
Connect the External NMEA to the serial Port 1, 2, 3, 4 or 5.
[MENU] + [MENU] + "ADVANCED" + [ENTER] + "Input/Output" + [ENTER]
+ "Port 1/2/3/4/5 Input" + [ENTER]. Then choose your preferred setting
among the NMEA available settings NMEA 1200-N81-N, NMEA 4800-N81-N,
NMEA 4800-N82-N, NMEA 9600-N81-N, NMEA 38400-N81-N and press
[ENTER] to confirm.
NOTE
Doing connection remember that only the Port 1 is optoisolated in input.
C-COM GSM Plus Connection
To connect the modem C-COM to the chart plotter follow the procedure:
[MENU] + [MENU] + "ADVANCED" + [ENTER] + "Input/Output" + [ENTER]
+ "Port 1 Input" + [ENTER] + "C-COM" + [ENTER]
