CS61884
DS485F3 29
12. OPERATIONAL SUMMARY
A brief summary of the CS61884 operations in hardware and host mode is provided in Table 7 .
12.1 Loopbacks
The CS61884 provides three loopback modes for
each port. Analog Loopback connects the transmit
signal on TTIP and TRING to RTIP and RRING.
Digital Loopback Connects the output of the En-
coder to the input of the Decoder (through the Jitter
Attenuator if enabled). Remote Loopback connects
the output of the Clock and Data Recovery block to
the input of the Pulse Shaper block. (Refer to de-
tailed descriptions below.) In hardware mode, the
LOOP[7:0] pins are used to activate Analog or Re-
mote loopback for each channel. In host mode, the
Analog, Digital and Remote Loopback registers are
used to enable these functions (Refer to the
Analog
Loopback Register (01h) (See Section 14.2 on
page 35), Remote Loopback Register (02h) (See
Section 14.3 on page 35), and Digital Loopback
Reset Register (0Ch) (See Section 14.13 on
page 37).
12.2 Analog Loopback
In Analog Loopback, the output of the
TTIP/TRING driver is internally connected to the
input of the RTIP/RRING receiver so that the data
on TPOS/TNEG and TCLK appears on the
RPOS/RNEG and RCLK outputs. In this mode the
RTIP and RRING inputs are ignored. Refer to
Figure 8 on page 30 . In hardware mode, Analog
Loopback is selected by driving LOOP[7:0] high.
In host mode, Analog Loopback is selected for a
given channel using the appropriate bit in the
Ana-
log Loopback Register (01h) (See Section 14.2 on
page 35).
NOTE: The simultaneous selection of Analog and
Remote loopback modes is not valid. A TAOS
request overrides the data on TPOS and TNEG
during Analog Loopback. Refer to
Figure 9 on
page 30 .
Table 7. Operational Summary
MCLK TCLK LOOP Receive Mode Transmit Mode Loopback
Active Active Open RCLK/Data Recovery Unipolar/Bipolar Disabled
Active Active L RCLK/Data Recovery Unipolar/Bipolar Remote Loopback
Active Active H RCLK/Data Recovery Unipolar/Bipolar Analog Loopback
Active L X RCLK/Data Recovery Power Down Disabled
Active H Open RCLK/Data Recovery TAOS Disabled
Active H L RCLK/Data Recovery Unipolar/Bipolar Remote Loopback
Active H H RCLK/Data Recovery TAOS Analog Loopback
L Active X Power Down Unipolar/Bipolar Disabled
L H X Power Down RZ Data Disabled
L L X Power Down Power Down Disabled
H Active Open Data Recovery Unipolar/Bipolar Disabled
H Active L Data Recovery RZ Data Remote Loopback
H Active H Data Recovery Unipolar/Bipolar Analog Loopback
H L Open Data Recovery Power Down Disabled
H L L Data Recovery RZ Data Remote Loopback
H L H Data Recovery Power Down Disabled
H H Open Data Recovery RZ Data Disabled
H H L Data Recovery RZ Data Remote Loopback
H H H Data Recovery RZ Data Analog Loopback
