RADWAG PUE C41H Indicator - Manual (Page 131)

- 131 -
27.6.1. Technical specification
Useful number of internal divisions 8 388 608
OIML class III
Number of verification divisions 6 000
Maximal change of input signal 19mV
Maximal voltage per verification divisions 3,3 µV
Minimal voltage per verification divisions 1µV
Minimal tensometer impedance 90 Ω
Maximal tensometer impedance 1200
Ω
Tensometer excitation voltage 5V
Types of tensometers 4 or 6 wires + shield
27.6.2. Colours of wires
RADWAG
Designation
Colour
Designation of soldering
pads on PCB’s.
+INPUT brown + 5V
-INPUT green AGND
+OUTPUT yellow + IN
- OUTPUT white - IN
+SENSE grey + REF
- SENSE pink - REF
EKRAN yellow-green
(according to the rule
of connecting shields)
