58 VP-747 - VP-747 Communication Protocol
Set Commands (F = Function)
Control Type Function Param 1
Param 2 Param 3 Param 4 Description
Set Get
0 1 327
0:Mode3
1280x768@60HZ
1:Mode3
1366x768@60HZ
- - - Mode Set Mode3
0 1 328
0:Manual (Default)
1:Auto
- - - Auto Image Mode
- 1 329
0~32767
1->ON, 0->OFF
bit 0: Chessboard
bit 1: Panel lock
bit 2: Menu
bit 3: Enter
bit 4: Left
bit 5: Up
bit 6: Down
bit 7: Right
bit 8: OSD
0~32767
1->ON, 0->OFF
bit 0: Program
Channel 8
bit 1: Preview
Freeze
bit 2: Program
Freeze
bit 3: Preview Blank
bit 4: Program Blank
bit 5: Preview PIP
bit 6: Program PIP
bit 7: Take
bit 8: Cut
bit 9: Diagonal
bit 10: Circle
bit 11: Corner
bit 12: Fade
bit 13: Wipe
bit 14: Square
0~32767
1-> ON, 0-
>OFF
bit 0: Preview
Channel 1
bit 1: Program
Channel 1
bit 2: Preview
Channel 2
bit 3: Program
Channel 2
bit 4: Preview
Channel 3
bit 5: Program
Channel 3
bit 6: Preview
Channel 4
bit 7: Program
Channel 4
bit 8: Preview
Channel 5
bit 9: Program
Channel 5
bit 10: Preview
Channel 6
bit 11: Program
Channel 6
bit 12: Preview
Channel 7
bit 13: Program
Channel 7
bit 14: Preview
Channel 8
- Keypad LED status
0 1 330
0: Off
1: On
- - - Low Latency Mode
