12 VP-747 - Connecting the VP-747
5 Connecting the VP-747
Always switch off the power to each device before connecting it to your
VP-747. After connecting your VP-747, connect its power and then
switch on the power to each device.
The VP-747 is a universal presentation matrix switcher/scaler that lets you choose
what sources to connect to the inputs. For example, you can connect just five
sources: an RGBHV source, two DVI/HDMI sources, an HDTV source and an
RGBS source (as the example in
Figure 3 shows).
To connect the VP-747 as illustrated in the example in Figure 3 , do the following:
1. Connect the following video sources:
 An HDMI source to the INPUT DVI/HDMI 1 connector
 An HDMI source to the INPUT DVI/HDMI 2 connector
 An HDTV satellite receiver source to the R/PR, G/Y/CV, and B/PB/C
BNC INPUT 6 connectors (PR/Y/PB)
 An RGBHV computer graphics source to the R/PR, G/Y/CV, B/PB/C,
HS/CS and V BNC INPUT 8 connectors (R, G, B, H, V)
2. Connect the PROGRAM OUT:
 DVI/HDMI connector to the plasma display
 VGA 15-pin HD connector to the analog display
 R/PR, G/Y, B/PB, (PR, Y, PB) BNC OUTPUT connectors to the YUV
acceptor, for example, a projector (PR,Y, PB)
3. Connect the PREVIEW OUT R/PR, G/Y, B/PB, HS and VS BNC OUTPUT
connectors to the display (R, G, B, H, V)
4. Connect the power cord.
