VP-747 - VP-747 Communication Protocol
Set Commands (F = Function)
Control Type Function Param 1
Param 2
Param 3
Param 4 Description
Set
Get
: Y 1 283
0
1
286
0: Channel 1
1: Channel 2
2: Channel 3
3: Channel 4
4: Channel 5
5: Channel 6
6: Channel 7
7: Channel 8
-
-
-
Audio Program input
source
0
1
287
-82 ~ 45
-
-
-
Audio Program Input
Volume,
-82 = Mute
0
1
288
-22 ~ 9
-
-
-
Audio Program Output
Volume,
-22 = Mute
0
1
289
0 ~ 127
-
-
-
Audio Program Input
Delay
0
1
290
0: Channel 1
1: Channel 2
2: Channel 3
3: Channel 4
4: Channel 5
5: Channel 6
6: Channel 7
7: Channel 8
-
-
-
Audio Preview input
source
0
1
291
-82 ~ 45
-
-
-
Audio Preview Input
Volume,
-82 = Mute
0
1
292
-82 ~ 45
-
-
-
Audio Preview Output
Volume,
-82 = Mute
0
1
293
0: Preview
1: Program
-
-
-
Audio headphone
source
0
1
294
-12 ~ 4
-
-
-
Audio Headphone
Volume, -12 = Mute
0
1
295
-6 ~ 6
-
-
-
Audio Bass
0
1
296
-6 ~ 6
-
-
-
Audio Treble0
0
1
297
-10 ~ 10
-
-
-
Audio Balance
-
1
298
0: Audio Follow Video
1: Audio Breakaway -
-
-
Audio Follow Video or
Audio Breakaway
0
1
299
0: Off
1: On
-
-
-
Audio Fade
0
1
300
0:None
1:Freeze
2:Blank
3:Freeze&Blank
-
-
-
Audio Mute-Follow
0
1
301
-
-
-
-
Audio TAKE
0
1
306
0: Off
1: On
-
-
-
TCPIP DHCP
0
1
307
0 ~ 255
0 ~ 255
0 ~ 255
0 ~ 255
TCPIP IP Address
0
1
308
0 ~ 255
0 ~ 255
0 ~ 255
0 ~ 255
TCPIP Subnet Mask
0
1
309
0 ~ 255
0 ~ 255
0 ~ 255
0 ~ 255
TCPIP Gateway
0
-
310
-
-
-
-
TCPIP Apply
0
1
311
0: Center
1: Top Left
2: Top Right
3: Bottom Left
4: Bottom Right
-
-
-
OSD Setting Menu
Position
0
1
312
0: 5 seconds
1: 10 seconds
-
-
-
OSD Setting TimeOut
