52 VP-747 - VP-747 Communication Protocol
Set Commands (F = Function)
Control Type Function Param 1
Param 2 Param 3 Param 4 Description
Set Get
5: 275%
6: 300%
7: 325%
8: 350%
9: 375%
10: 400%
11:Custom
0 1 179 0 ~ 32 - - -
Program Scale Custom
Zoom
0 1 180 -16 ~ 16 - - -
Program Scale Zoom H-
Pan
0 1 181 -16 ~ 16 - - -
Program Scale Zoom V-
Pan
0 1 182
0: Off
1: On
- - - Program PIP On/Off
0 1 183
0: Picture-In-Picture
1: Picture + Picture
2: Split
- - - Program PIP Type
0 1 184
0: Channel 1
1: Channel 2
2: Channel 3
3: Channel 4
4: Channel 5
5: Channel 6
6: Channel 7
7: Channel 8
- - - Program PIP Source
0 1 185
0: 1/25
1: 1/16
2: 1/9
3: 1/4
4: Custom
- - - Program PIP Size
0 1 186 0 ~ 128 - - -
Program PIP
H-Position
0 1 187 0 ~ 128 - - -
Program PIP
V-Position
0 1 188 1 ~ 255 - - -
Program PIP
H-Size
0 1 189 1 ~ 255 - - -
Program PIP
V-Size
0 1 200
0: Off
1: On
- - - Program PIP Frame
0 1 201
0:Red
1:Green
2:Blue
- - -
Program PIP Frame
Color
0 1 202
0: Native
1: 640x480 x60Hz
2: 640x480 x75Hz
3: 800x600 x50Hz
4: 800x600 x60Hz
5: 800x600 x75Hz
6: 832x624 x75Hz
7: 852x480 x60Hz
8: 1024x768 x50Hz
9: 1024x768 x60Hz
10: 1024x768 x75Hz
11: 1280x720 x60Hz
12: 1280x768 x50Hz
13: 1280x768 x60Hz
14: 1280x800 x60Hz
15: 1280x1024x50Hz
16: 1280x1024x60Hz
- - -
Program Output
Resolution
