VP-747 - VP-747 Communication Protocol
Set Commands (F = Function)
Control Type Function Param 1
Param 2
Param 3
Param 4 Description
Set
Get
0
1
216
2~(HS-13)
-
-
-
Program Input Setting
User Mode VW
0
1
217
15~(VT-VA-1)
-
-
-
Program Input Setting
User Mode VS
0
1
218
480~1200
<= (VT-16)
-
-
-
Program Input Setting
User Mode VA
0
1
219
0: -
1: +
-
-
-
Program Input Setting
User Mode VP
0
1
220
25 ~ 165 (Integer
Value)
0 ~ 999 (Decimal
Value)
-
-
Program Input Setting
User Mode OCLK
0
1
221
0: Off
1: On
-
-
-
Program Input Setting
Enable
0
-
222
-
-
-
-
Program Input Setting
User Mode Save
0
1
223
0: Custom 1
1: Custom 2
2: Custom 3
3: Custom 4
Program Custom
Output Target
0
1
224
512~3071
-
-
-
Program Output Setting
User Mode HT
0
1
225
32~(HS-48)
-
-
-
Program Output Setting
User Mode HW
0
1
226
80~(HT-HA-12)
-
-
-
Program Output Setting
User Mode HS
0
1
227
640~1920
<= (HT-92)
-
-
-
Program Output Setting
User Mode HA
0
1
228
0: -
1: +
-
-
-
Program Output Setting
User Mode HP
0
1
229
384~2047
-
-
-
Program Output Setting
User Mode VT
0
1
230
2~(HS-13)
-
-
-
Program Output Setting
User Mode VW
0
1
231
15~(VT-VA-1)
-
-
-
Program Output Setting
User Mode VS
0
1
232
480~1200
<= (VT-16)
-
-
-
Program Output Setting
User Mode VA
0
1
233
0: -
1: +
-
-
-
Program Output Setting
User Mode VP
0
1
234
25 ~ 165 (Integer
Value)
0 ~ 999 (Decimal
Value)
-
-
Program Output Setting
User Mode OCLK
0
-
235
-
-
-
-
Program Output Setting
User Mode Save
0
-
236
-
-
-
-
Program Output Setting
User Mode Set Current
0
1
237
0:Keystone
1:Anyplace
2:Rotation
Program Geometry
Application
0
1
238
0: Front
1: Ceiling
2: Rear
3: Rear Ceiling
-
-
-
Program Geometry
Location
0
1
239
-40 ~ 40
-
-
-
Program Geometry H-
Keystone
0
1
240
-30 ~ 30
-
-
-
Program Geometry V-
Keystone
0
1
241
0: Top Left
1: Top Right
2: Bottom Left
3: Bottom Right
0:H
1:V
-2000 ~ 2000
-
Program Geometry
Diagonal Projection
