VP-747 - Understanding the VP-747 21
7 Understanding the VP-747
This section describes the:
• UNIVERSAL inputs, see
• PREVIEW/PROGRAM outputs, see
Section 7.1
• Switching/Scaling of an input, see
Section 7.2
• PIP feature, see
Section 7.3
• Panel Lock, see
Section 7.4
7.1 Understanding the UNIVERSAL Inputs
Section 7.5
The VP-747 has eight sets of inputs (Each set consists of five BNC connectors:
R/Pr, G/Y/CV, B/Pb/C, Hs/Cs, and Vs); each set can be programmed to operate
as composite video, s-Video, component video, RGB/YUV, RGBS, RGsB, or
RGBHV. INPUT 1 and INPUT 2 can also accept DVI/HDMI inputs.
The VP-747 is a universal presentation matrix switcher/scaler: you choose what
type of source to connect to each input. You can connect different video types or
the same or similar video types. See the examples in
Figure 3 and Figure 4 .
7.2 Understanding the PREVIEW/PROGRAM Outputs
The VP-747 has two outputs: a PREVIEW output, and a PROGRAM output. Each
of these outputs functions independently and has DVI/HDMI connectors and VGA
connectors, as well as sets of five BNC connectors used to output one of the
following: RGB, RGBHV, or component video): R/P
R , G/Y, B/P B , H S , and V S .
The HDMI signal is usually HDCP protected. We recommended
using an HDCP compliant display, otherwise the HDMI output does
not appear on the screen
i
