VP-747 - VP-747 Communication Protocol
Set Commands (F = Function)
Control Type Function Param 1
Param 2
Param 3
Param 4 Description
Set
Get
1:Anyplace
2:Rotation
Application
0
1
118
0: Front
1: Ceiling
2: Rear
3: Rear Ceiling
-
-
-
Preview Geometry
Location
0
1
119
-40 ~ 40
-
-
-
Preview Geometry H-
Keystone
0
1
120
-30 ~ 30
-
-
-
Preview Geometry V-
Keystone
0
1
121
0: Top Left
1: Top Right
2: Bottom Left
3: Bottom Right
0: Horizontal
1: vertical
-2000 ~ 2000
-
Preview Geometry
Diagonal Projection
0
-
122
-
-
-
-
Preview Geometry
Diagonal Projection
Reset
0
1
123
-20 ~ 20
-
-
-
Preview Geometry
Pincushion/Barrel
0
1
124
-180 ~ 180
-
-
-
Preview Geometry
Rotation
0
-
125
-
-
-
-
Preview Geometry
Reset all
0
1
151
0: Channel 1
1: Channel 2
2: Channel 3
3: Channel 4
4: Channel 5
5: Channel 6
6: Channel 7
7: Channel 8
-
-
-
Program Input Source
0
1
152
0: RGBHV
1: RGBS(PC)
2: RGsB(PC)
3: RGBS(Video)
4: RGsB(Video)
5: YCbCr
6: Y/C
7: Video
8: HDMI
-
-
-
Program Input Type
HDMI can only be
selected for Channel 1
or Channel 2
0
1
153
0: Auto
1: NTSC
2: PAL
3: PAL-M
4: PAL-N
5: NTSC 4.43
6: SECAM
7: PAL 60
-
-
-
Program Input Video
Standard
0
1
154
1 ~ N
-
-
-
Program Input Main
Source
H-Position
N: unfixed, changes with
Input Mode
0
1
155
2 ~ N
-
-
-
Program Input Main
Source
V-Position
N: unfixed, changes with
Input Mode
0
1
156
-A ~ A
-
-
-
Program Input
Frequency
A = (max - min)/2
min = 0 , max =
