VP-747 - Operating the VP-747 35
8.1.5 The Utility Menu Items
Figure 17: Utility Screen
Utility Screen Functions
Setting
Function Default
TCP/IP
Setting
DHCP: Off or On Off
IP Address 192.168.1.39
Subnet Mask 255.255.255.0
Gateway 192.168.1.254
Apply: Apply settings
OSD Menu Position: Center, Top Left, Top Right, Bottom
Left or Bottom Right
Center
Time-Out: 5, 10, 20, 30, 60, 90 seconds or Off 30 Sec
Misc.
Settings
Logo: Off, On or Custom
ON for the start up Kramer logo to appear on the
screen; OFF to disable the logo.
CUSTOM to select the downloaded custom Logo
(Flash ROM)
Downloaded via USB (Logo Download)
On
Save Lock (see Section 8.1.5.1 )
Input Lock: Off or On (see Section 8.1.5.2 On )
Background: Blue, Black or Disable Analog Sync Black
Blank Color: Black or Blue
Event Mode: Off or On
If On is selected, the LCD displays “Invalid operation in the
event of pressing any program button”
Off
Baud Rate: 9600 or 115200 115200
Firmware Download: Download the firmware via the
USB connection, select the correct file from the
memory stick and Confirm
Do not press any buttons while the firmware is downloading
Logo Download: Download a new logo via the USB port
using a memory stick (see Section 8.1.5.3 )
