VP-747 - Technical Specifications

Technical Specifications

INPUTS:

2 HDMI/DVI inputs connectors (HDMI and HDCP version 1.2) on DVI connectors

8 sets of universal BNC connectors: R/Pr, G/Y/CV, B/Pb/C, Hs/Cs, and Vs, each

programmable for use as CV, YC, RGB, YCbCr, YPbPr, RGBS or RGBHV

PREVIEW

OUTPUT:

1 x HDMI/DVI input connector (HDMI and HDCP version 1.2) on a DVI connector

1 x VGA (VGA through UXGA) on a 15-pin HD connector

1 x RGBHV/YPbPr on BNC connectors

PROGRAM

OUTPUT:

1 x HDMI/DVI input connector (HDMI version 1.2 and HDCP version 1.2) on a DVI

connector

1 x VGA (VGA through UXGA) on a 15-pin HD connector

1 x RGBHV/YPbPr on BNC connectors

OUTPUT

RESOLUTIONS:

640x480 60Hz, 640x480 75Hz, 800x600 50Hz, 800x600 60Hz, 800x600 75Hz,

832x624 75Hz, 852x480 60Hz, 1024x768 50Hz, 1024x768 60Hz, 1024x768

75Hz, 1280x720 60Hz, 1280x768 50Hz, 1280x768 60Hz, 1280x800 60Hz,

1280x1024 50Hz, 1280x1024 60Hz, 1280x1024 75Hz, 1366x768 50Hz, 1366x768

60Hz, 1400x1050 50Hz, 1400x1050 60Hz, 1440x900 60Hz, 1600x1200 50Hz,

1600x1200 60Hz, 1680x1050 60Hz, 1920x1080 50Hz, 1920x1080 60Hz,

1920x1200 60Hz, 480px60Hz, 576p, 720p 50Hz, 720p 60Hz, 1080i 50Hz, 1080i

60Hz, 1080p 50Hz, 1080p 60Hz, 1080p 24Hz (for HDMI), 480px59.94Hz,

720px59.94Hz, 1080ix59.94Hz,

1080px23.97Hz,

1080px29.97Hz,

1080px59.94Hz

or one of 4 Custom resolutions

For the most up-to-date resolution list, go to our Web site at

http://www.kramerelectronics.com

CONTROLS:

Front panel buttons, high contrast LCD, IR remote control, Ethernet, AUDIO

CONTROL, RS-232 and RS-485 for optional T-bar remote controller

ADDITIONAL

CONTROLS:

Freeze, zoom, different selectable vertical refresh rates, ProcAmp control, output

image scaling, Picture-In-Picture, and aspect ratio change

POWER

SOURCE:

100-240 VAC, 50/60Hz 65VA

DIMENSIONS:

19” (W), 9.3” (D), 3RU (H) rack mountable

WEIGHT:

5.5kg. (12.2lbs) approx.

ACCESSORIES: IR remote control, power cord, rack “ears”, and null-modem adapter
OPTIONS:

VP-747T control panel

Specifications are subject to change without notice at

http://www.kramerelectronics.com

9.1

Default Communication Parameters

RS-232 Communication Protocol

Baud Rate:

9600 / 115200

Data Bits:

Stop Bits:

Parity:

None

Command Format:

HEX

Example (select channel 1 as program input):

Y01510CR

Ethernet

IP Address:

192.168.1.39

TCP Port Number:

5000

Network Mask:

255.255.255.0

Default Gateway:

192.168.1.1
