VP-747 - Operating the VP-747 41
8.4 Operating via the Ethernet
The control application lets you control the VP-747 by clicking the desired buttons
in the control application screen (which includes all the front panel buttons). To
control the
VP-747 via the Ethernet/Serial Port:
1. Connect the Ethernet port (see Section 6.4 ) of the VP-747 to the Ethernet
port of your PC or connect the serial port of your VP-747 to the serial port of
your PC (see 6.1 Section
2. Install and configure the Control Application (see
).
Section 8.4.1
8.4.1 Installing and Running the Configuration Software
).
To install the VP-747 Control Application, do the following:
1. Insert the product CD into your CD-ROM drive.
You can download the software from our Web site on http://www.kramerelectronics.com .
2. Save the zip file on your computer.
3. Run the installer setup.
4. Respond to the installation wizard prompts.
8.4.2 Configuring the Ethernet Connection
Double click the VP747.exe icon. The VP747 Control Application main screen
appears (see
Figure 21 ).
You can configure the Ethernet (the VP-747 communication port is 5000) in any
one of the following ways; via
• The Ethernet connection, using the Lantronix device software
• The VP-747 Device menu (the OSD) or via the Control Application menu:
, and then setting the IP Address, subnet mask
and so on, and then clicking Apply
• RS-232 communication between the PC and the VP-747, and setting the IP
Address through the Com port menu in the Control Application
