Specification Sheet

Specification

Sheet

PERFORMANCE

AND POWER REQUIREMENTS

DIMENSIONS

DEPTH: 58 in.

WIDTH: 50 in.

HEIGHT: 100 in.

TORQUE:

100,000 ft. lbs.

MAXIMUM PIPE ROTATION:

50 degrees

WRENCH SIZE RANGE:

4"

__

9 1/2" OD tool joints

SPINNER SIZE RANGE:

3"

__

9 1/2" OD tube

AIR POWER SOURCE:

100 psi

@ 2-10 cfm

HYDRAULIC POWER SOURCE:

2,600 psi @ 20-35 gpm

HYDRAULIC POWER SOURCE TYPE:

Closed Center System

WEIGHT:

3,700 lbs.

GRIP, SPIN, MAKE UP & RESET CYCLE TIME:

10 sec. or less

GRIP, BREAK OUT, SPIN & RESET CYCLE TIME:

12 sec. or less

7

Specification Sheet

NOTE

If the only available hydraulic power unit is open center, then a Hawk supplied hydraulic
converter
(Part # J-80) is required. Running the HawkJaw with a constant volume hydraulic
power unit may result in bodily injury and will cause damage to the HawkJaw and to the
hydraulic power unit.
