Raise/Lower Cylinder
Drawings
113
Drawings
Item
Part #
Part Name
Piston Seal
W
ear Ring
Static Seal
Rod Seal
Rod W
iper
Cotter Pin 1 1/2" Long
Blind Clevis Pin
Rod Clevis Pin
Cotter Pin 3 1/2" long
Rod Assembly
Seal Retainer
Rod Clevis
Barrel Assembly
*
*
*
*
*
061-2572-2
061-2572-3
061-2572-4
061-2572-5
061-2572-6
061-2572-7
061-2572-8
061-2572-9
1-1
1-2
1-3
1-4
1-5
2
3
4
5
6
7
8
9
1
1
1
1
1
4
1
1
1
1
1
1
1
Quantity
Per Unit
20h20s
3/98
* These parts available only
in kit #061-H20S-RK
Part # 061-H20S
ref. pp. 142, 148
Arrow denotes the direction
the seal should face.
