Hawk Industries Hawkjaw Sr. Manual ALS Serial Numbers 1 to 100 - Manual (Page 112)

Raise/Lower Cylinder
112 Drawings
20rlcyl
3/98
**Replace piston nut
cotter pin / dowel pin.
Part # 061-H20
Old Style Cylinder
Quantity
Per Unit
1
1
1
1
1
2
1
2
1
1
1
4
1
1
1
1
1
1 1
2
3
4
5
*6
**7
*8
*9
*10
*11
12
13
14
*15
16
17
18 061-HPI1
061-HPI2
061-HPI3
061-HPI4
061-HPI5
061-HPI6
061-HPI7
061-HPI8
061-HPI9
061-HPI10
061-HPI11
061-HPI12
061-HPIG
061-HPIR
061-HPIW
061-HPIN Cylinder Head
Cylinder Cap
Rod Assy. ( #3 & #5 are one complete assy.)
Cylinder Tube Assy.
Piston ( #3 & #5 are one complete assy.)
Piston Seal
Piston Nut ( Includes cotter pin and dowl pin)
Barrel Seal
Rod Seal
Gland Seal
Rod to Piston Seal
Tie Rod
Gland
Retainer Plate
Wiper
Tie Rod Nut
Top Clevis Pin (See page 142 for part numbers)
Bottom Clevis Pin (See page 142 for part numbers)
Part Name Item Part #
* These parts are available only in kit # 061-H20-RK.
WARNING
** Bodily injury may result if piston nut cotter pin is not replaced during maintenance.
