Hawk Industries Hawkjaw Sr. Manual ALS Serial Numbers 1 to 100 - Manual (Page 115)

N/A
N/A
N/A
1
3
3
2
2
2
4
6
6
1
1
1
1
1
1
1
N/A
Quantity
Per Unit
Item Part #
Drawings
115 Drawings
*H1
*H2
*H3
H4
H5
H5A
H6
H7
H8
H9
H9A
H10
H11
H12
H13
H21
H29
H30
H39
H123F
NOTE
To increase the speed of the Raise/Lower cylinder, use a 7/32" allen wrench to adjust the meter
on both ends of the sandwich valve H6 at Port VR/L counter-clockwise. To decrease the
speed, adjust the meter clockwise.
NOTE
To increase the speed of the Tilt cylinder, use a 7/32" allen wrench to adjust the meter on both
ends of the sandwich valve H6 at Port VF/B counter-clockwise. To decrease the speed, adjust
the meter clockwise.
NOTE
To adjust the spinner motor sequence valve at Port VG/S, use a 3/16" allen wrench to rotate
the sequence valve counter-clockwise until the chain moves before the doors close. Next,
rotate the adjustment clockwise until the spinner doors close before the chain moves. Rotate
one half-turn clockwise. Lock in the adjustment.
Port Part Name
Vertical/Tilt Manifold
Main Manifold
Grip Manifold
Main Relief Valve
Directional Valve
Bolt Kit for Item H5
Sandwich Valve
Sandwich Valve
Directional Valve
Directional Valve
Bolt Kit for Item H9 & H8
Directional Valve
Directional Valve
Sequence Valve
Pressure Reducer Valve
Flow Control Valve (25.0GPM)
Check Valve
Relief Valve
Gage
Main Hydraulic Block Fitting Kit
* These parts are available only in Assy. # 061-H123 without valves.
061-H123
061-H123
061-H123
061-H4
061-H5
061-H5A
061-H6
061-H7
061-H8
061-H9
061-H9A
061-H10
061-H11
061-H12
061-H13
061-H21
061-H29
061-H30
061-H39
061-H123F
N/A
N/A
N/A
VMR
VR/L, VF/B
N/A
VR/L, VF/B
VR/L, VF/B
V1, V2
VM3, VG1, VG2, VG3
N/A
VS1,VS2,VSR,VSP,VTR,VTP
VM/B
VG/S
VGP
FC
VGC
VGR
GP
N/A
Main Hydraulic Block Assembly
Warning
The Hawkjaw includes specially modified valves for extreme
environments. Any attempt to substitute standard components
will reduce reliablity and performance, and void warranty.
20mnbk2
10/97
Change
