Part Name

Quantity

Per Unit

Item

Part #

Spinner Grip Cylinder

Drawings

1
*2
3
4
5
*6
*7
8
9
*10
*11
*12
13

031-70017
031-10022
031-5A049A
031-4E320A
031-4E319A
031-10041
031-10071
031-20031
031-73438
031-10004
031-10353
031-10029
031-20008

Piston
U-Cup Seal
Rod Assy.
Tube Assy., Top Cyl.
Tube Assy., Bottom Cyl.
"O" Ring Seal
Back-Up Seal
Retainer Ring
Head
Wiper Seal
Rod Seal
"O" Ring Seal
Lock Nut

2
4
2
1
1
2
2
2
2
2
2
2
2

* These parts are available only in kit # 031-24CYL25RK.
