Hawk Industries Hawkjaw Sr. Manual ALS Serial Numbers 1 to 100 - Manual (Page 3)

Table of Contents
Table of Contents
3 Table of Contents
Introduction 2
Table of Contents 3
Warranty 6
Specification Sheet 7
Ordering Instructions 8
Installation 9
Hanging Cable Location 9
HawkJaw Location 9
Hanging Cable Requirements 10
Hydraulic Requirements 11
Air Requirements 12
Raise/Lower Cylinder Hook - Up 13
Winch Hook - Up 14
Operation 17
Start-up Procedure 17
Adjust for Make Up 18
Adjusting the Wrenches 18
Adjusting the Spinner 19
Position for Make Up 20
Setting Make Up Torque 22
Make Up 23
Adjust for Break Out 24
Adjusting the Wrenches 24
Adjusting the Spinner 25
Position for Break Out 26
Break Out 28
Maintenance & Repair 31
Wrench Maintenance 31
Die Pivot Blocks 31
Wrench Hook 32
Wrench Nut 32
Hook Pivot Bearing Cap 32
Grip Cylinder Pivot Points 33
Torque Cylinder Pivot Points 33
Tilt Cylinder Pivot Points 33
Mounting Arm Pivot Points 34
Filter Maintenance 35
Hydraulic Filter 35
Air Filters 36
Changing the Hook Dies 37
Hook Dies 37
Continued on next page.
