Setting Make Up Torque
1. Follow the steps on pages 17-21.
2. Turn the Selector Switch (SS) to
Make.
3. Use the Red needle adjust (RNA)
to rotate the Torque gauge red
needle (RN) to the desired
torque.
4. Rotate the Torque Set knob (K)
counter- clockwise as far as the
Torque Set knob (K) will turn.
5. Press and hold Spin (S) until the
stand rotates down to the
shoulder.
6. Release Spin (S). Immediately
press and hold Grip (G).
7. While holding down Grip (G),
press and hold Torque (T).
While holding down both Grip
(G) and Torque (T), rotate the
Torque Set knob (K) clockwise.
8. When the Torque gauge needle
(TN) reaches the desired torque,
stop rotating the Torque Set knob
(K).
9. Release both Torque (T) and
Grip (G) at the same time.
K T
Shown set for 35,000 ft. lbs.
TN RNA RN
S G SS
Operation 22
